Conductive slip ring belong to the category of electrical contact sliding connection application, it is also called the collector ring, or rotary joint, rotating electrical interface, slip ring, collecting ring, ring back, coil, commutator, adapter, is to realize the image of two relative rotating mechanism, data signal and power transmission precision transmission device, then what is the process of conductive slip ring? Let's understand it together!



　

1, cap type slip ring, with flange, small volume, generally used in high-speed ball, camera inside.

2, through the slip ring, as the name implies, this type of slip ring has a hole in the middle, used to install fixed on the shaft, this kind of slip ring is generally palm width, generally used for packaging machinery, medical equipment and other large mechanical equipment.

3, disk slip ring, some similar to the hole slip ring, but the hole of the disk slip ring is small or not, the height is very low, flat like a plate, more used for revolving doors and other equipment with height restrictions above.

4, wind power slip ring, mainly used for wind turbines, according to the different requirements of the generator, the design of the shape is not the same.

The above is for you to introduce the content of the conductive slip ring, more content is welcome to call you for consultation!
